GEA + WALDNER DOSOMAT 10.2 ESL, Year 2015

Ref.: 16193 Cup Fill & Seal
Description: UHT process with a rotary filler Waldner Dosomat
UHT
- 10 L/min
- Plates and tubular exchanger – possibility to use one or the other (GEA)
- Including one aseptic homogenizer, 3 pistons, 2 stages, 210 bars max
Storage tanks:
- 3 aseptic tanks 1,000 L each, built in 2015 (AMS)
Whipped cream/mousse:
- Tubular cooling exchanger
- Mondomix type VA – 15 built in 2015
Rotary filler:
- Waldner Dosomat 10.2 ESL – in 3A – and UL-execution/Machine built in 2015
- 95 mm cup – 5.3 to 7 oz (150 to 200 g)
- Pulse light decontamination for cup
- 40 strokes/min, in 2 lines so 4,800 cups/h
- Filler 1 (main filler): 2.7 to 16.9 oz (77 to 479 g)
- Filler 2 (topper or mousse): 0.5 to 2 oz (14 to 56 g)
